Dual Cryogenic Pressure Temperature Transducer双低温压力温度传感器
Model 7730
GP:50 的 7730 低温系列在一台设备中提供低至 -320 °F (-196 °C) 的压力和温度测量。远程安装的
电子设备提供 4-20 mA、0 至 5 Vdc 的高电平输出或高精度的各种数字协议。提供 100 或 1,000 Ω 铂 RTD 以及双模拟输出。
特征:
• Cryogenic service down to -320 °F (-196 °C) 低温服务降至-320°F(-196°C)
• Isolated electronics provide 4-20 mA, 0-5 Vdc ordigital outputs 隔离电子设备提供4-20mA、0-5Vdc或数字输出
• Remote electronics via stainless steel armored cable 远程电子设备通过不锈钢铠装电缆安装
• High accuracy, 0.3% RSS standard 精度高,0.3%RSS标准
• Lightweight, <10 oz. (0.2 kg) 轻质的, <10 oz. (0.2 kg)
• Hydrogen and LOX compatibility options available 氢气和LOX的兼容性选项可用
• Platinum RTD 白金RTD
应用:
- Liquefied fuel pressures
- Manifolds, propulsion systems
- Military and defense programs
- Liquid gas custody transfer
选项:
- 0 to 5 Vdc, 0 to 10 Vdc or 4-20 mA output
- RS232, RS485 and Can outputs
- Custom probe lengths
- Zero and span adjustments
- Optional electrical connections
- High-temp version to +350 °F (+177 °C) (see Model 7780)
- Various MIL-SPECS available. Consult factory
