Flight Heritage Low Level Pressure Transducer
低压压力传感器
Model 7100
GP:50 的 7100 型飞行遗产低电平压力传感器旨在提供高达 ±0.1% FSO 的高精度测量。其飞行历史跨越 25 年,使其成为要求苛刻的航空航天和国防应用的理想选择,包括可能存在较高冲击和振动水平的应用。其紧凑轻巧的设计有助于在空间受限的环境中轻松安装。
特征:
• Aircraft and space flight heritage
• Compact, lightweight stainless steel design
• High accuracies up to ±0.1% FSO (BFSL)
• Wide operating temperature range from -70 °F to
+275 °F (-56 °C to +135 °C)
• Secondary containment rated to 4,500 PSI (310 BAR)
应用:
• Commercial and defense satellites
• Launch vehicles
• Unmanned aerial vehicles
• Military and civilian aircraft
• Ground support and engine test stands
选项:
• “B+ and S Class” amplified electronics available
• Temperature output
• Inconel, Hastelloy, and Monel wetted parts
• Wide selection of pressure ports and electrical connections
• Various MIL-SPECS available. Consult factory.
