FW-1710 Flucon Flowmeter,超纯液体流量计,电子流量计
FW-1710 Flucon Flowmeter for low flowrate of ultra pure liquid
Wetted parts and connection are constructed of PFA and FW-171 O
series flow meters are available in integral flow adjustment valve.
These super litter unit features allows for precise and easy to
control a flow control and special chemical resistance with PTFE
packing.
Features特征
-Particle free, none ion contamination -无颗粒，无离子污染
– Structure of PFA tube connection -PFA管接头的结构
– Flow measurement: gas, DI wate『, chemical -流量测量：气体、去离子水、化学
– Compact size -紧凑型尺寸
– Confidence test for all of products -所有产品的置信度测试
– Built-in control valve-内置控制阀
– Wide for range available to meet all requirements -适用范围广，可满足所有要求
– Cleaned ult『asonic DI water & vacuum package in a clean room -在洁净室中清洁超声波去离子水和真空包
Specification 规格
– Measuring object : Gas, Liquid(viscosity < 5.0cP) -测量对象：气体、液体（粘度<5.0cP）
– Range : Water·Min 20 CCM / Max 2 LPM -范围：水·最小20 CCM/最大2 LPM
GAS – Min 500 CCM / Max 50 LPM 气体-最小500 CCM/最大50 LPM
– Accuracy: 土5%full scale -准确度：土5%满刻度
-OP.Press : Max 5 kg/cm’ -操作压力：最大5 kg/cm’
-OP.Temp: Max SO•c -操作温度：最大SO•c
