韩国进口流量计,Flucon FW1520流量计,Wooil Flucon flowmeter,流量计
Stainless Steel Flow Meter For Middle Flowrate
Specification
– Measuring object : Gas, Liquid(viscosity < 5.0cP)
– Range : Water – Min 5 LPM / Max 20 LPM
GAS – Min 50 LPM / Max 600 LPM
– Accuracy : ±3 % full scale
– OP.Press : Max 8 kg/cm2
– OP.Temp : 0~90
Applications
– DI water, gas, chemical supplylines for semicond
-uctor equipment
– Built-in control valve, easy measurement and
control by needle valve
– Utility flow measurement of small lab
– High purity and corrosive liquid equipment
such as gas purifier and gas scrubber
– Fields in microbiology, chemistry and medicine
using high purity fluid
