Pellicle Coatings
在现有丰富的涂层库存基础上,NPC 现提供低损耗、平均反射/透射比为 45%/55%(R/T)的涂层,适用于以下波长范围:400nm–700nm、700nm–900nm、1µm–2µm 以及 3µm–5µm。
National Photocolor 可以根据具体的单一波长和入射角应用需求,为 P 偏振、S 偏振或非偏振光选择合适的已镀膜薄膜(pellicles)。同时可提供透射率测试/说明文档。
NPX9-50/50 R/T @6328Å for Helium Neon Lasers

NPZ-33/67 R/T for the visible and near IR region (R/T available from 10/90 to 33/67)

NPIN-30/30 metallic for the visible and near IR

NP-40-40/40 R/T metallic through the Visible through IR

NPAL-88/<01 aluminum, neutral over the visible range (R/T available from 52/20 to 88/<01)
