Jisico真空干燥箱、真空干燥箱J-DVO1、真空干燥箱J-DVO2
产品：
真空干燥箱J-DVO1、真空干燥箱J-DVO2
● 特殊设计的硅橡胶密封圈确保了气密的真空状态。
● 采用微处理器PID自整定控制器，数字设定与显示。
● 自动断电电路可防止过热。
● 观察窗上装有透明聚碳酸酯板，提高了用户的安全性。
Model | J-DVO1 | J-DVO2 | |||
| Type | Indirect heating(air jacket) & decompressing | ||||
| 730×530/570×580 | 830×630/670×680 | |||
| 300×350×300 | 400×450×400 | |||
| 31 | 72 | |||
| Temperature | range | Ambient+10℃ ~ 250℃ | |||
| accuracy | ±2.0℃ at 100.0℃ | ||||
| controller | PID controller | ||||
| regulator | SSR type | ||||
| Thermocouple | K type(CA) | ||||
| 1,800 | 2,400 | |||
| Vacuum range | 0 ~ 760mmHg | ||||
| Vacuum loss | Less than 3.5Kpa/24Hr | ||||
| Ultimate pressure degree | 0 ~ 760mmHg (101.3Kpa) | ||||
| Vacuum Ø10.0, Vent Ø10.0 | ||||
Observation window | Reinforced glass 12T | Reinforced glass 19T | |||
| Safety device | Electric leakage breaker (ELB), overheating protection system | ||||
| Shelves | 3ea | ||||
| Material | interior | Stainless steel plate | |||
| exterior | Steel plate with powder coated finish | ||||
| Power source & consumption | AC 230V 50/60Hz 1phase | AC 230V 50/60Hz 1phase | |||
| 63 | 97 | |||
| Certification | CE | – | |||
