Slim Submersible Level Transmitter
Model 313S
超薄潜水液位计
313S 型具有与我们广受欢迎的 313L 相同的所有功能,但具有直径为 0.685 英寸(17.4 毫米)的超薄外壳,适用
于安装空间有限的应用。所有 GP:50 潜水式液位变送器均采用坚固的防漏不锈钢结构、雷电浪涌保护和集成的疏水过滤器,可提供准确的液位测量,并为所有类型的液位应用提供多年的无腐蚀服务。
特征:
• Slim 0.685” (17.4mm) diameter housing
• 0 to 20” WC thru 300 PSI (211 meters WC)
• 4-20 mA output
• Rugged, welded, leak-proof stainless steel
construction
• Silicon sensor technology
• Up to 0.10% FSO accuracy
• Hydrophobic breather filter
•Slim 0.685 ” (17.4mm)直径的外壳
•0到20“WC通过300 PSI(211米WC)
•4- 20ma输出
•坚固,焊接,防漏不锈钢结构
•硅传感器技术
•高达0.10%的FSO精度
•疏水呼吸过滤器
应用:
• Sewage lift and pump stations
• Deep well and borehole
• Groundwater monitoring
• Shipboard level control
• Weirs, wells, pond, reservoir, and dam leve
选项:
• Lightning suppression
• Additional Hytrel cable and Tefzel® jacketed cable lengths
