德国Vision&Control TZB95-G525-24V远心平行光源
德国Vision&Control TZB95-G525-24V远心平行光源 特征
- 远心LED照明-平行（准直）光束路径
与远心透镜相结合的理想背光
用于有针对性地突出显示边缘和表面结构，以及检测透明材料中的夹杂物和缺陷
集成在外壳中的照明控制器-亮度可调
连接：带有M8连接器的电缆
多样化的附件选择和广泛的配件
德国Vision&Control TZB95-G525-24V远心平行光源 技术数据
Technical data
| Light-emitting surface | Diameter: 95 mm |
| Light design | Telecentric |
| Light colour (typ.) | Green, 525 nm |
| Operating mode | Switchable continuous operation |
| Special feature | Brightness setting manually on the potentiometer |
| Operation voltage | 24 VDC (10 – 30 V) |
| Power consumption | max. 3.6 W (150 mA at 24 VDC) |
| Housing material | Aluminium, black anodised |
| Optical material | Glass |
| Filter thread | M100 x 1 – depth 4 mm |
| Weight | 3,130 g |
| Degree of protection | IP50 |
| Safety class | Class III, safety extra low voltage (SELV) |
| Risk group (DIN EN 62471) | Freie Gruppe |
| Ambient temperature | -10 °C bis +45 °C |
| Cable | |
| Cable length | 1,500 mm |
| Cable diameter | 6.5 mm |
| Cable structure | 4 x 0.25 mm² and 3 x 0.5 mm² |
| Drag chain suitable | yes |
