Sterlitech CF042 Cell Assembly, Crossflow, Acrylic (CF042A) CF042 膜池组件，错流，丙烯酸（CF042A）
咨询热线 15821107090
Sterlitech
Acrylic
Specifications
| CF016 | CF042 | Sepa | |
|---|---|---|---|
| Active Membrane Area | 20.6 cm2 (3.2 in2) | 42 cm2 (6.5 in2) | 140 cm2 (22 in2) |
| Hold-Up Vol. | 13 mL (0.44 oz) | 17 mL (0.57 oz) | 70 mL (2.4 oz) |
| Connections | Feed:1/4 in FNPT (base of cell) Concentrate1/4 in FNPT (base of cell) Filtrate:1/8 in FNPT (top of cell) | Feed:1/4 in FNPT (base of cell) Concentrate1/4 in FNPT (base of cell) Filtrate:1/8 in FNPT (top of cell) | Feed:1/4 in FNPT (base of cell) Concentrate1/4 in FNPT (base of cell) Filtrate:1/8 in FNPT (top of cell) |
| Outer Dimensions | 12.7 x 10 x 8.3 cm (5 x 4 x 3.25 in) | 12.7 x 10 x 8.3 cm (5 x 4 x 3.25 in) | 16.51 x 21.3 x 5 cm (6.5 x 8.38 x 2.07 in) |
| Active Area Dimensions | 4.52 x 4.52 cm (1.78 x 1.78 in) | 9.207 x 4.572 cm (3.625 x 1.8 in) | 9.7 x 14.7 cm (3.81 x 5.78 in) |
| Slot Depth | 0.23 cm (0.09 in) | 0.23 cm (0.09 in) | 0.19 cm (0.075 in) |
| Slot Width | 39 mm (1.54 in) | 39 mm (1.54 in) | 95.3 mm (3.75 in) |
 |  |  |  |  | |  |  |  |  |  | | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Material | Acetal (Delrin) | 316 Stainless Steel | Virgin PTFE | Acrylic | Acetal (Delrin) | 316 Stainless Steel | Virgin PTFE | Acrylic | Hastelloy™ | 316 Stainless Steel | Acrylic | Hastelloy™ |
| Maximum Bolts Torque Setting (in-lbs) | 60 | NA | 15 | 45 | 60 | NA | 15 | 45 | 70 | NA | 45 | 70 |
| Maximum Fittings Torque Setting (in-lbs) | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 |
| Max Pressure | 69 bar (1000 psig) | 69 bar (1000 psig) | 27.6 bar (400 psig) | 27.6 bar (400 psig) | 69 bar (1000 psig) | 69 bar (1000 psig) | 27.6 bar (400 psig) | 27.6 bar (400 psig) | 69 bar (1000 psig) | 69 bar (1000 psig) | 15.2 bar (220 psig) | 69 bar (1000 psig) |
| Max Temperature | 82°C (180°F) | 150°C (302°F) | 260°C (500°F) | 88°C (190°F) | 82°C (180°F) | 150°C (302°F) | 260°C (500°F) | 88°C (190°F) | 150°C (302°F) | 150°C (302°F) | 88°C (190°F) | 150°C (302°F) |
