代理Power technology PM90(685-100)G55B1半导体激光管模块
Power technology用于 OEM 应用的 685nm、100mW 半导体激光管模块。Power technology PM90（685-100）G55B1 激光器专为需要这种独特波长、稳定输出功率和良好波长稳定性的应用而设计。新型 PM 模块提供的可选功率是以前激光器的两倍，以及改进的近乎圆形的光束轮廓。Power technology PM90（685-100）G55B1 具有具有高质量光学元件的聚焦或准直光束，提供 685nm 的典型波长，并在 3.3-9VDC 范围内最佳运行。该模块的多功能性使其成为各种用途的理想选择，包括机器视觉、生命科学、3D 扫描和对齐应用。准直后，激光模块的光束直径为 1.16 x 1.80 毫米，可提供近乎圆形的轮廓。此外，还提供偏射极限聚焦光束。
美国Power technology激光器规格：
Power technology PM90(685-100)G55B1半导体激光管模块规格：
| Wavelength (nm) | 685 |
|---|---|
| Laser Safety Class | Class 3b |
| Wavelength Tolerance | +-10nm |
| Power | 100 |
| Warranty | 1 Year |
| Power Units | mW |
| Pwr Stability Over Temp Rng | ±3% |
| Noise RMS(10Hz-5MHz) | <0.5% |
| Color | Red |
| Beam Shape | Circular, Elliptical |
| Default Optical Configuration | Focused at 5 feet |
| User Focusable | Yes |
| Transverse Mode Structure | TEMoo |
| Polarization Ratio | >100:1 at 100% power |
| Polarization State | Linear |
| Beam Pointing Stability | <10 |
| Operating Mode | CW |
| Operating Voltage | 3.3-9 |
| Operating Voltage Units | VDC |
| Max Operating Current (mA) | 125 |
| Operating Current Units | mA |
| Product Weight (lbs.) | 0.28 |
| Platform | PM |
