LC系列线性滑台专为研发测试、自动化及其他需要快速定位轻载物体的工业应用而设计。
该系列提供200mm至400mm多种行程选择，配备两种丝杠导程规格：2mm导程可实现更高定位精度，12mm导程则适用于高速应用场景。标准配置包含大扭矩17步进电机及行程限位开关，所有限位开关和电机电缆均通过电机后侧的9针接口连接器集中布线。
传动系统采用不锈钢ACME丝杆与自润滑塑料驱动螺母组合，实现无背隙运行。创新的自动磨损补偿机构可确保滑台在整个生命周期内维持零背隙精度。
LC系列支持灵活的多轴组合配置，可搭建XY、XZ或XYZ多轴运动平台。
全系列产品均采用6061铝合金精密加工成型，表面经过专业黑色阳极氧化处理。
Travel Range | 200 mm, 300 mm, 400 mm |
Resolution | 0.04 µm (2 mm pitch lead screw) 0.24 µm (12 mm pitch lead screw) |
Accuracy | 0.0006 mm/mm of travel |
Uni-directional Repeatability | ±2 µm |
Bi-directional Repeatability | 15 µm |
Encoder | Optical rotary encoder mounted to rear of motor, 4000 CPR with Index (Optional) |
Max. Speed | 12 mm/sec (2 mm pitch lead screw) 70 mm/sec (12 mm pitch lead screw) |
Maximum Load | 22.6 kg (50 lb.) |
Limit Switch Type | Mechanical, normally closed |
Stage Weight | LC-200: 2.8 kg (6.2 lb.) | LC-300: 3.3 kg (7.3 lb.) | LC-400: 3.8 kg (8.4 lb.) |
Material | Aluminum Alloy Construction |
Finish | Black Anodize |
Operating Temperature | 0°C to 50°C |
