Item # DP0125-A1113-X1-0001, Diaphragm Pump, 2.5 LPM, -9.84 InHg to 4.35 PSI, 12VDC, Brush
Direct Current (DC) Rated Voltage | 12 V |
Maximum Pressure | 30 kPa0.3 bar0.3 kgf/cm²-9.8 inHg to 4.27 psi4.35 psig |
Duty Cycle | Continuous |
Coil Insulation Class | E or its Equivalent (JETL) |
Gross Weight | 0.18 lb0.08 kg |
Measure System | EUROSIU.S.A |
Attainable Vacuum | -33.3 kPa-250 mmHg-333 mbar-9.84 inHg |
Free Air Displacement | 2.5 L/min0.088 ft³/min |
Maximum Current | 0.5 A |
Life Expectancy | 200 h |
Straight Nipple Inlet and Outlet Outside Diameter (OD) | 3 mm |
