加拿大Current Scientific Corporation NN 3040船用热成像相机

Current Scientific Corporation Night Navigator™3040在陀螺稳定传感器平台中集成了HD LWIR非制冷热成像仪、高清（HD）日间摄像头/低光。

Thermal Camera
Sensor Type	HD Uncooled Long Wave Infrared (LWIR), 8-14µm
Resolution	1024×768 pixels, 30fps
Field of View	68.4° to 9.9°
Optical Zoom	7x
Detection Range	NATO Target >6.7km
Day Camera
Resolution	1920×1080 pixels, 30fps
Field of View	63.7° to 2.3°
Optical Zoom	30x continuous zoom
Low Light Camera	0.0015 lux
Payload Specifications
Stabilization	Gyro and video stabilization
Pan Range	Continuous 360° AZ rotation
Tilt Range	+/-90° elevation movement, including stow position
Weight	≤25 kg [55lbs]
Dimensions	427mm H x 273mm W [17in H x 11in W]
System Interface
Video Streaming	RTSP H.264 with Picture-in-Picture or 2 simultaneous video streams
Control	Over IP network
Radar / AIS	ARPA target, radar cursor, AIS target tracking over NMEA 0183 via RS422 or RS232 or Network
Features
Environmental	IP67
Operational Temperature	-20°C to +50°C
Video Tracking	Optional
Control Options	Video integrated into UI / Control only UI / Compact Controller / Rugged Rigid Grip / 2-Button Joystick
Third Party Interface	Protocol for integration into navigation system / video management system / C2
Video Recording	Network recording of two video streams on VMS or dedicated DVR
Power Requirements
Voltage	24 to 36VDC
Max. Consumption	320W
