高功率偏振不敏感光环行器

特性

低插入损耗和PDL
高隔离和高回波损耗
无环氧光路

应用程序

EDFA, DWDM和OTDR
DWDM和OADM网络
双向传输系统

产品规格

Parameter	Unit	Specifications
Grade		P	A
Operating Wavelength	nm	1550±30
Insertion Loss	dB	≤0.90¹⁾ ≤1.1²⁾	≤1.2¹⁾ ≤1.4²⁾
Minimum Isolation	dB	≥40¹⁾ ≥35²⁾
Polarization Dependent Loss	dB	≤ 0.15
Return Loss	dB	≥ 50
Channel Crosstalk	dB	≥ 50
Optical Power	W	≤ 1, 2, 3, or 5
Polarization Mode Dispersion	ps	≤ 0.10
Operating Temperature	°C	– 0 to +70
Storage Temperature	°C	– 40 to +85
Package Dimensions	mm	A=Ø5.5 x L63 M=Ø5.5 x L50

Note:

1) Measured at center wavelength under 23°C for all SOP.
2) Measured at center wavelength under 0~70°C for all SOP.

All values referenced are without connector.

美国AC Photonics Inc. 光环行器 1310 ~ 1600nm SM环行器高功率偏振不敏感光环行器
