带遥感头的 RPS-100 控制器
| Part Number | Range | Output |
|---|---|---|
| RPS-100-14 | 2″-14″ | Isolated Form C Relay |
| RPS-100-72 | 5″-72″ | Isolated Form C Relay |
| RPS-100-240 | 10″-240″ | Isolated Form C Relay |
| RPS-100-14-500 | 5″ – 36″ | 0 – 10VDC and 4 – 20 mA Analog |
| RPS-72-500 | 5″ – 72″ | 0 – 10VDC and 4 – 20 mA Analog |
| RPS-240-500 | 10″ – 240″ | 0 – 10VDC and 4 – 20 mA Analog |
| Specifications: | RPS-400-30 |
|---|---|
| Operational Range: | Adjustable 5″ to 30″ |
| Power Input: | 12 – 30VDC |
| Input Current: | 30mA |
| Ambient Temperature: | -0 to 50°C or 32 to 122°F |
| Humidity: | 0 to 95% Non-Condensing |
| Housing: | Acetal Plastic with Silicone Sensing Face |
| Output: | NPN Open Collector Transistor |
| Current Load: | 60mA continuous |
| Transducer Frequency: | 222 kHz |
| Response Time: | 30ms – On / 30ms – Off |
| Weight: | 4 ounces |
| Specifications: | RPS-150 |
|---|---|
| Operational Range: | 40″ Models – Adjustable 2″ to 40″ 80″ Models – Adjustable 5″ to 80″ |
| Hysteresis: | 40″ Models – Adjustable 0.5″ to 40″ 80″ Models – Adjustable 1″ to 80″ |
| Power Input: | AC Models – 105 to 130VAC DC Models – 20 to 30VDC |
| Input Current: | 15 mA VAC or 35 mA VDC |
| Ambient Temperature: | 0 to 60°C or 32 to 140°F |
| Humidity: | 0% -95% Non-Condensing |
| Housing: | PBT Plastic, Limit Switch Style |
| Outputs: | 2 Solid State Relays N.O. & N.C. Isolated 1500VRMS 2 to 130VAC or VDC 100 mA DC or 50mA AC Continous Short Circuit Protected |
| Transducer Frequency: | 38.5kHz |
| Response Time: | 40″ Models – On = 60ms & Off = 60ms 80″ Models – On = 120ms & Off = 120ms |
| Weight: | 9.5 ounces |
| Accuracy: | 0.187″ or 0.5% (0.005) of the range, whichever is greater at 70°F. |
