PAVE 同轴RF密封 气密同轴连接器

同轴RF密封 - 气密同轴连接器，除非图纸上另有说明，否则所有电气屏蔽均为隔离或浮动，且具有端到端的电气连续性。 PAVE的气密同轴连接器RF密封是双向的，可以双向密封压力或真空。对于超过300 psi（20 bar）的压力，如果改变图纸上显示的压力方向，请与销售工程师联系。

无论是低压还是高压，从1 bar到1000 bar，以及从低真空到10^-8 Torr的高真空，PAVE几乎可以提供无限选择的气密同轴电气针连接器类型或屏蔽RF同轴电缆密封，温度范围从低温-200℃到200℃，具体取决于设计和客户的实际操作和测试要求。PAVE的气密环氧密封取代了气密玻璃-金属连接器密封，提供了更多的电气连接器设计选项。在大多数情况下，如果需要，现有设计图纸也可以适应更高的压力、更低的泄漏率和更广的温度范围。 气密同轴连接器包括BNC 50欧姆和75欧姆，SMA低频和高频（+2-100 GHz使用需要特殊设计），SHV，SMB，SMC，N，双轴等，既有双面连接器也有单面样式。大多数气密同轴连接器屏蔽都是隔离或浮动的，也可以订购接地的。此外，还提供气密多针圆形连接器和气密密封的矩形组合D-Sub连接器设计。 几乎任何类型的气密同轴连接器或屏蔽电缆都可以以几乎任何组合和电线长度进行气密密封。隔板的多种气密贯通安装样式可供选择，包括卡口螺母O形圈、NPT、活塞O形圈、Conflat®法兰等，甚至包括定制工程设计。通过或绕过电缆没有可检测到的气体或液体泄漏。我们随时可以协助选择合适的具有成本效益的气密密封设计。

安装接口 双边，单边 总线 PAVE 描述代码, 外壳 & 线缆 线缆 1 AWG # 线缆 2 AWG # 图纸号码 #
¾” o-ring piston seal cable seal RG 178 SP6H-E-150-1-RG178-18-18 25k psi 1 RG 178 4792
3/8″ piston o-ring hermetic cable seal 1 SP6H-E-150-1-RG316-18-18 1 RG 316 5752
1″ o-ring face seal Dual In-Stock 1 VS15L-SS-150-1-BNC-BNC isolated shield 0261
½” NPT dual 1 PT8-SS-150-1-BNC-BNC 1 1532
½” NPT dual 1 PT8-SS-150-BNC-BNC (XL) 1 2095
½” NPT threads dual or single 1 PT8-BNP-150-1-BNC-BNC 75 OHM 1 75 ohm 18 4424
1” o-ring face seal dual side connect 1 VS15L-SS-150-BNC-BNC 1 4054
1″ o-ring face seal dual 1 VS15L-SS-150HV-1-BNC-BNC GROUNDED SHIELD 1 BNC 5302
½” o-ring face seal connector 1 VS8-SS-150-1-BNC-PIN 1 probe 4523
½” o-ring face seal dual in-stock 1 VS8-SS-150-SMA-SMA isolated shield See Quick Ship List 1 1162
½” 2x o-ring face seal dual connect 1 VS8x2OR-SS-150-1- SMA- SMA 1 3817
½ o-ring face seal dual 1 VS8L-SS-150-1-SMA-SMA long threads 2 Ghz max isolated 1 24 5774
½ o-ring face seal dual capacitance seal 1 VS8-SS-150-1-SMA-SMA 26 GHz 100% shielding isolated 1 20 4708
1″ o-ring face seal PAVE-Mate® II 2 VS15L-SS-150-2-2.92-2.92 40GHz SMK 2.92mm 2 coaxial 5240
3/4″ o-ring face seal PAVE-Mate® II 1 VS12L-SS-150-1-65GHZCOAX-F-30F SMK 1.85mm 12 coaxial 5251
¾ o-ring face seal cable 1 VS12L-SS-150-1-100GHZCOAX-2.5F-20F SMK 1.0mm 1 100 GHz 4765
¾ o-ring face seal cable 1 VS12L-SS-150-1-100 GHZ COAX-2.5-20 1mm SMK SMA 1 100 GHz 4567
3/4″ o-ring face seal single 2 VS12L-SS-150-2-100GHZCOAX-F-24F 1.0mm 2 1.0mm 5230
KF25 NW25 QF25 DN25 flange dual 1 NW25-SS-150-1-2.92mm-2.92mm Ka-Band SMA 2.9mm SMK 40 GHz 1 22 4527
1/16″ NPT Cable Seal 600 bar 2 PT1-SS-2-RG178-1-1M 2 rg178 3473
1″ NPT dual UHF coax 1 PT16-SS-150-1-UHF-UHF 1 1768
¼” NPT single side disconnect 1 PT4-SS-150-SMA-RG196-60mm LOW TEMP 1 rg196 4023
¼” NPT single side connect 1 PT4-SS-150-SMA-RG196-50mm 1 2410
1″ NPT dual side connect 1 PT8-SS-150-TNC-TNC 1 2172
½” SAE thread single 1 SO8S-SS-200-1-TE26-SMB-6 1 PTFE 26 4830
½” SAE dual side connect 1 SO8-SS-150-SMA-SMA (grounded) 1 1646
1/2″ o-ring straight thread cable seal 2 shielded SO8-SS-150-1-TPS28100RF-3T-7T twinax Samtec 2 twinaxial 28 5730
½” SAE dual side connect 1 SO8S-SS-150-1-TWINAXE20-60-6 1330
½” o-ring piston seal cable 9 SP8/100-E-150-8/1-PC24/RG178-16-16 8 24 1 RG 175 4582
½” piston o-ring attenna seal 1 SP8A-E-150-1-STORM421710-POST-35 SMA 1 sma cable 3748
1/2″ o-ring piston seal RG178 cable 1 SP8L-E-150-1-RG178-45-30 1 RG178 5126
¾” piston o-ring hermetic cable seal 1 SPF12-E-150-1-RG142/RG316-6-18 1 rg142/316 2808
¾” o-ring face seal dual side connect 2 VS12-SS-150-1-TWINAX/Triax 2 20 1155
1;” p-ring face seal dual 2 VS15L-SS-150-1-TWINAX-TWINAX twinax 4948
1 ¼” o-ring face seal jam nut dual side connect 2 VS18-SS-150-2-TWINAX-TWINAX 20 5335
¾” piston o-ring single side connect 2 SPF12L-B-80-2-TE20-TWINAX/Triax-2 2 20 2220
1″ o-ring face seal cable seal 2 VS15L-SS-150-1-TWINAX24-264-72 100 ohm twinax 2 26 4894
7/16″-28 o-ring seal single side connect 2 SP5.5-E-150-2-TE20-TWINAX-12 2 20 2664
17.37mm piston o-ring cable seal 3 SP11L-E-150-2/1-PC24/RG405/U-12-38 2 PVC 24 RG 405 4330
¾” o-ring face seal cable seal 7 VS12-SS-150-1/6-RG316/TE26-24-24 1 RG 316 6 26 5661
¾” o-ring face seal dual side connect 1 VS12-AL-150-F-F 1 2577
¾” o-ring face seal single side connect 1 VS12L-SS-150-1-BNC-SC 1 1861
1″ o-ring face seal dual side connect 1 VS15L-SS-150-BNC, 75 OHMs 1 75 ohms 2800
1″ o-ring face seal dual side connect 1 VS15L-SS-150-MHV-MHV 1 2954
1″ o-ring face seal dual side connect 1 VS15L-SS-150-1-MHV-MHV GROUNDED SHIELD 1 MHV 5303
1″ o-ring face seal dual side connect 1 VS15L-SS-200-TNC 1 1527
1″ o-ring face seal dual 1 VS15L-SS-150HV-1-BNC-BNC 1 18 2964
1¼” o-ring face seal dual side connect 1 VS18-SS-150-BNC-BNC 1 1750
1″ o-ring face seal dual sided 1 VS18-SS-150-SHV-SHV isolated shield See Quick Ship List 1 1518
1¼” o-ring face seal dual side connect 1 VS18-SS-200-N-N 1 1526
½” o-ring face seal dual side connect 1 VS8-SS-150-SMA-SMA 1 1162-1
NW40 KF40 dual 8 NW40-SS-150-4-BNC-BNC 8 single SMA 5149
¼” o-ring face seal single 1 VS4N-SS-150-1-22-RPSMA-2 reverse polarity SMA 1 single SMA 4546
½” o-ring face seal hermetic cable seal 1 VS8-SS-80-1-RG179-96-48 75 ohm 1 1557
½” o-ring face seal dual side connect 1 VS8-SS-150-1-SMC MICRODOT 1 3349
½” o-ring face seal dual side connect 1 VS8-SS-150-1-SMB 1 2144
13mm o-ring face seal single side connect 1 VSBNC-SS-200-1-CRTFE18-BNC-13 1 18 2628
custom flange seal single side connect 2 CONNECTOR FUEL GAGE NSN 5935-00-673-8388 57F908572-3 Blackhawkcopter 2 0075
½” NPT hermetic cable seal 1 PTN8-SS-150-1-RG62U-48-6 93 ohm 1 rg62 3271
¾” SAE hermetic cable seal 2 SO12L-SS-80-2-RG316-10-30 2 1504
1.25″ o-ring face seal connector 4 VS18-SS-150-2-TWINAX-TWINAX dual twinax 5490
1″ NPT cable seals PT16-SS-200-3-RG59-18T-18T RG59 5476
1⅝” o-ring face seal dual side connect 3 VS22-SS-150-3-BNC-BNC 3 BNC 4319
1⅜” o-ring face seal dual side connect 3 VS22-SS-150-2/1-BNC/MHV-BNC/MHV 3 1699
½” piston o-ring cable seal 3 SPF8-E-150-3-MICROCOAX-11-14 3 micro coax 3722
1″ o-ring face cable seal 3 VS15-SS-150-3-RG178-24-24 3 RG 178 5736
1″ o-ring face cable seal 3 VS15-AL-150-1/2/1-RG174/RG58-72-18 RG174 5483
1″ o-ring face cable seal 3 VS15L-SS-150-3-USB-96 USB A-48 USB B 3 USB A to B 3819
 l single 3 VS22-SS-150-3-J3 COAX-BNC-425 BNC J3 coax Wilcoxon 4377
M24 o-ring face seal low noise cables 3 VSM24XL-SS-150-3-AC0005-433-39 5100
NW40 flange dual 4 NW40-SS-150-4-TWINAX-TWINAX 4 twinax 4803
1″ o-ring seal cable seal 4 VS15L-SS-150-1- ESATA-16M-18M Esata E-SATA 4018
1″ piston o-rings cable seal 7 SP16-E-200-5/2-RG316/PVF20-1-2m 4088
1″ piston o-ring seal coax cables 4 SP16-E-150-4-0024A0311-7-78 coax 3650
1″ o-ring face seal dual 2 VS15L-SS-150-1-RCA-RCA 2 RCA 5158
1″ o-ring face seal cable 5 VS15-AL-150-1/2/2-RG174/RG58/KE30-72-29 1 RG174 2 RG58 2 Type E TC pairs 5482
3/4″ mNPT cable 4 PT12-SS-150-4-RG316-144-144 4 RG 316 5267
17,37mm piston o-ring cable 1 SP11L-E-150-1-RG316-60-24 5 RG 316 5211
1-1/16″ SAE single side connect 5 SO16L-SS-80-3/2-RG316/18HV 5 1306
1″ o-ring face seal hermetic cable seal 5 VS15L-SS-150-3-RG58-6T-6T 5 2435
1¼” o-ring face seal hermetic cable seal 5 VS18-SS-150-5-RG58-6T-6T 5 1774
M24 metric thread cable seal 6 VSM24XL-SS-150-6-AC0005-433-39 low noise 6 Low Noise 5127
1¼” o-ring face seal hermetic cable seal 5 VS18-SS-150-5-RG59-6T-72T 75 ohm 5 2505
1″ piston o-ring cable seal 6 + 2 gas lines SP16-E-150-6/2-RG174/.125SS-18 6 rg174 3860
1¼” o-ring face seal hermetic cable seal 6 VS18-SS-150-5/1-RG316/REYNOLDS HV-36-36 rg316 18kv 26 3509
1¼” o-ring face seal hermetic cable seal 6 VS18-SS-150-5/1-RG174/1788022- 5 rg174 1 hv 2963
1¼” o-ring face seal hermetic cable seal 6 VS18-SS-150-6-RG178-48-48 6 2393
1¼” o-ring face seal hermetic cable seal 6 VS18-SS-150-6-RG316-180-40FE6PA 6 1540
1¼” o-ring face seal hermetic cable seal 7 VS18-SS-150-7-RG174+C-12-120 7 1461
1/2″ piston -ring seal cable seal 1 SP8A-E-150-1-STORM421710-POST-12 SMA 1 COAX 5386
Flange o-ring face seal PCB antenna 12 SPF14X-T-150-3/9-RG178/24 printed circuit board antenna 3 RG178 9 26 5277
NW40 KF40 dual side connector 7 NW40-SS-150-7-SMA-SMA 5686
custom flange seal dual side connect 8 FL54/18-AL-150-8-RG178 or 196-DSUB-DSUB combo dsub hermetic 8 coax 3205
½” piston o-ring PVC/PTFE 9 SP8/100-E-150-8/1-PC24/RG178-16-16 8 24 1 rg 178 4582
1-1/16″ SAE hp 8 SP16-E-200-8-RG178-1-2M 8 rg178 3530
8 coax+2 #26 SP16S-E-150-8/2-RG178/E26-39-3 8 RG175 26 2 4942
25.3mm piston o-ring seal hermetic cable seal 8 SP16-E-80-2/1/5-RG178/RG179/TE28 50 ohm 75 ohm 8 1574
1-¼” o-ring face seal cable seal 8 VS18-SS-150-7/1-RG174/REYNOLDS2896-85FT-10FT 7 RG174 1 HV 4333
2¾” conflat flange Servo stepper cables 9 plus shields CF275-SS-150-1/1-CBLPW/CBLFB-125T-229T 4 14 5 20 4756
M24 metric thread cable seal 9 VSM24XL-SS-150-9-AC0005-433-39 low noise 9 Low Noise 5128
1⅝” conflat flange cable seal 9 VS22-SS-150-3/6- TWINAX /COAX-60-60 3 twinax 6 rg178 4172
2¾” conflat flange hermetic cable seal 10 CF275-SS-150-10-HVC-36-36 10 1470
2¾” conflat flange cable 10 CF275-SS-150-10-RG188DS-48-48 10 rg 188 RG 188DS 4583
2¾” conflat flange hermetic cable seal 10 CF275-SS-150-10-RG178-36-36 10 1471
NW40 flange cable 10 NW40/VS18-SS-150-10-RG174-84BNC-12SMB 10 rg 174 5281
1¼” o-ring face seal hermetic cable seal 10 VS18-SS-150-10-RG178-36-36 10 rg178 2915
1¼” o-ring face seal hermetic cable seal 10 VS18-SS-150-10-RG58/U-8-12 10 2537
1¼” o-ring face seal cable 10 VS18-SS-150-10-RG174-72-72 10 RG174 4520
1 1/2″ o-ring face seal single 11 D38999/24-AL-150-11-5024A1311-30 8 Cheminax 5224
1⅝” o-ring face seal hermetic cable seal 11 VS22-SS-150-11-RG178-60-60 11 1389
2¾” piston o-ring hermetic cable seal 11 SPF12-E-150-4/5/1/1-TEE24/26/RG179/ USB-120-30cm 75 ohm 9 24-26 USB rg179 3833
1.25″ o-ring face seal cable 16 VS18-SS-150-11/5-CCSC/K34-20-91cm 11 ultra coax FEP cables #32 5 #34 Kapton 5543
1⅝” o-ring face-seal cable 12 VS22-304SS-150-12-J3-4T-300 12 J3 coax 4517
1-1/5″ o-ring face-seal cable seal 14 VS22-304SS-150-12-RG316-4T-165T 12 RG316 4358
1⅞” o-ring face seal cable seal splice 12 VS26-SS-150-12-RG316/RG58-4T-115T 12 12 RG58 4684
M24 o-ring face seal low noise cables 12 VSM24XL-SS-150-12-AC0005-433-39 5099
2¾” conflat flange hermetic cable seal 13 CF275-SS-150-13-R24A0024-30-30 13 1416
2½” o-ring face seal hermetic cable seal 13 VS32L-AL-150-13-RG59U-480-480 13 0681
1-⅝” o-ring face seal cable seal 16 VS22-SS-150-15/1-RG178/REYNOLD 15 RG174 1 HV 4334
1¼” piston o-ring custom hermetic connector 17 SP20-E-150-16/1-COAX/TE24-#22P-18 16 1 coax 2948
⅝” o-ring face seal submersible + hermetic cable seal 16 VS10-ss-150- 15 24 1 coax 1456
D38999/23Y single side connect 16 D38999/23Y*-E-150-6/10-RG179/TZ24-P247PS1 75 ohm 16 20 2635
2.75″ o-ring face seal hermetic connector 16 VS44-SS-150-4-RCN900724-76T-66T twinax quadrax Twinax cables Quadrax connector quadrax twinax twinax 5582
1⅝” o-ring face seal dual sided 16 VS22-SS-150-4-9- QUADRAX PS quadrax twinax 100 ohm 4 quadrax #9 4874
1⅝” o-ring face seal dual sided 16 VS22-SS-150-4-QUADRAX-PIN-PIN quadrax twinax 100 ohmethernet 4 rugged d-sub 100 ohms 4886
1⅝” o-ring face seal single side connect 16 VS22-SS-150-16-RG316-240-40FG1 16 rg316 3199
1⅝” o-ring face seal single side connect 16 VS26-SS-150-16C-RG179-240-40FG 75 ohm rg179 2887
1″ NPT with DSUB PTFE 17 PT16-B-150-1-AXO PATCH200B-70-48 17 24 3618
1⅞” o-ring face seal coaxial cable seal 18 VS26-SS-150-18-RG316/RG58-4T-115T 18 RG316 RG 58 4703
1 1/4″ mNPT nipple cable seal 19 PTN20-SS-150-19-RG174-35T-35T MICRODOT 19 RG 174 5755
1⅝” o-ring face seal cable twinax 100 ohm 20 shielded VS22-304SS-150-10-SP28-96-96 100 ohm twinax 20 twinax 28 4725
1⅝” o-ring face seal cable twinax 100 ohm 20 shielded VS22-SS-150-10-TWINAX30-96-96 20 twinax 100 ohm 4776
1⅝” o-ring face seal single side connect 20 VS22-SS-150-20-RG178-60-60 20 2529
M36 o-ring face seal low noise cables 18 VSM36XL-SS-150-18-AC0005-433-39 5098
NW40 flange hermetic cable seal 29 VS26-SS-150-29-RG179-144-QDB 75 ohm 29 0880
2½” o-ring face seal single side connect 29 VS32-SS-150-29-CX-3899940RN 29 COAX 3254
2½” o-ring face seal hermetic cable seal 30 VS32-SS-150-30-RG316-2-2m 30 2482
70mm flange single 32 D38999/20-SS-150-32-RG178-5.3-20278102R18 32 rg178 4470
flange mount single 32 D38999/20-SS-150-32-RG178-5.5-20278102R18 32 rg178 4436
1 7/8″ o-ring face seal hermetic cable seal 32 VS26-SS-150-32-RG178-42T-42T SMB 32 rg178 5219
1⅞” o-ring face seal cable seal 36 VS26-SS-150-4/32-TZ20/TWINAX-3.5M-3.5M 4 20 32 Twinaxial 4383
1⅞” o-ring face seal cable 37 VS26-SS-150-37-MPA08-22T-48T 1 rg 178 3939
NW40 flange hermetic cable seal 38 NW40-SS-150-38-MICTOR-73-24 38 2751
1.25″ piston o-ring seal data bus cable ETFE 38 SP20-E-200-19-TSP22-0.5M-0.5M Cheminax 10599 22 70 ohm 5112
1⅝” o-ring face seal hermetic PTFE 40 VS22-SS-200-20-TSP20-168-72 twisted pair 40 20 4366
1⅝” o-ring face seal hermetic cable seal 40 VS26-SS-150-40-RG178-24-24 40 2561
2½” o-ring face seal cable 40 VS32-SS-150-40-TE12S-10-10m 40 shielded #12 12 4403
NW50 KF50 cable seal low vac 84 NW50-SS-150-72/12-TWINAX/COAX-37T-21.7T 72 TWINAX 12 Coax 5374
1⅝” o-ring face seal hermetic cable seal 72 VS22-SS-150-36TSP-100 OHM TWINAX-5M-5M 72 TWINAX 2791
