FLC激光二极管模块

FLC激光二极管模块

FLC激光二极管模块是一种易于使用的即插即用激光系统，适用于广泛的军事、工业和医疗应用。 FLC激光二极管模块适用于服装、布料、纸张、木材、石头和金属等材料的定点和目标指定、光谱、测量设备、激光显示、打印、生物医学、患者定位、材料处理、激光展示、对齐和定位。 激光提供了广泛的投影范围，包括可调线、均匀或高斯、单点和十字线。不同的系列提供了广泛的颜色和强度，即使在最暗的材料下也能最大限度地提高投影的视觉外观。 FLC激光二极管模块主要型号：
 Model Wavelength Power Power Range Operating Temp. Package
FPYL-375-XXT-XS 375nm 0,050W 1 to 50mW 10 to 35°C
FOLM-404-180-LM 404nm 0,180W 10 to 40°C
FOLM-405-12-LM 405nm 0,012W 10 to 45°C
FOLM-405-25-LM 405nm 0,025W 10 to 45°C
FOLM-405-40-LM 405nm 0,040W 10 to 45°C
FOLM-406-12-LM 406nm 0,012W 10 to 45°C
FOLM-406-25-LM 406nm 0,025W 10 to 45°C
FOLM-406-40-LM 406nm 0,040W 10 to 45°C
FPYL-442-XXT-LC 442nm 0,030W 1 to 30mW 20 to 30°C
FPYL-445-XXT-LC 445nm 0,030W 1 to 30mW 20 to 30°C
FPYL-445-XW 445nm 8,000W 5 to 8W 10 to 35°C
FPYL-447-XXT-LC 447nm 0,030W 1 to 30mW 20 to 30°C
FPYL-447-XW 447nm 8,000W 5 to 8W 10 to 35°C
FCBM-CW02-005 450nm 0,005W 10 to 60°C
FPYL-450-XXT-LC 450nm 0,030W 1 to 30mW 20 to 30°C
FPYL-450-XXT-XS 450nm 0,030W 1 to 30mW 10 to 35°C
FAL-450-X.X-GS 450nm 0,050W 0.4 to 50mW
FPYL-488-XXT-XS 488nm 0,050W 1 to 50mW 10 to 35°C
FPYL-488-XXT-LC 488nm 0,070W 1 to 70mW 20 to 30°C
FPYL-514.5-XXT-LC 515nm 0,040W 1 to 40mW 20 to 30°C
FCGM-GD02-001 515nm 0,001W -10 to 50°C
ML-EL-520-01-Mini 520nm 0,001W -10 to 50°C
FPYL-520-XXT-LC 520nm 0,010W 1 to 10mW 20 to 30°C
FPYL-520-XXT-XS 520nm 0,050W 1 to 50mW 10 to 35°C
FAL-520-X.X-GS 520nm 0,080W 1 to 80mW
FCGM-C002-001 532nm 0,001W 10 to 40°C
FCGM-C803-001 532nm 0,001W 10 to 40°C
FCGM-C803-01L 532nm 0,001W 10 to 40°C
FCGM-CF02-001 532nm 0,001W 10 to 40°C
FCGM-CF09-001 532nm 0,001W 10 to 40°C
FCGM-CW02-001 532nm 0,001W 10 to 40°C
FCGM-CW02-01L 532nm 0,001W 10 to 40°C
FCGM-CW09-001 532nm 0,001W 10 to 40°C
FCGM-CW09-01L 532nm 0,001W 10 to 40°C
FCGM-PS02-001 532nm 0,001W 10 to 40°C
FCGM-C002-005 532nm 0,005W 10 to 40°C
FCGM-C803-005 532nm 0,005W 10 to 40°C
FCGM-C803-05L 532nm 0,005W 10 to 40°C
FCGM-CF02-005 532nm 0,005W 10 to 40°C
FCGM-CF09-005 532nm 0,005W 10 to 40°C
FCGM-CW02-005 532nm 0,005W 10 to 40°C
FCGM-CW02-05L 532nm 0,005W 10 to 40°C
FCGM-CW09-005 532nm 0,005W 10 to 40°C
FCGM-CW09-05L 532nm 0,005W 10 to 40°C
FCGM-GD02-005 532nm 0,005W -10 to 50°C
FCGM-PS02-005 532nm 0,005W 10 to 40°C
FCGM-CF02-010 532nm 0,010W 10 to 40°C
FCGM-CF09-010 532nm 0,010W 10 to 40°C
FCGM-CW02-010 532nm 0,010W 10 to 40°C
FCGM-CW02-10L 532nm 0,010W 10 to 40°C
FCGM-CW09-010 532nm 0,010W 10 to 40°C
FCGM-CW09-10L 532nm 0,010W 10 to 40°C
FCGM-PS02-010 532nm 0,010W 10 to 40°C
FCGM-CF02-020 532nm 0,020W 10 to 40°C
FCGM-CF09-020 532nm 0,020W 10 to 40°C
FCGM-CW02-020 532nm 0,020W 10 to 40°C
FCGM-CW02-20L 532nm 0,020W 10 to 40°C
FCGM-CW09-020 532nm 0,020W 10 to 40°C
FCGM-CW09-20L 532nm 0,020W 10 to 40°C
FCGM-PS02-020 532nm 0,020W 10 to 40°C
FCGM-XP01-030 532nm 0,030W 10 to 40°C
FCGM-XP01-030L 532nm 0,030W 10 to 40°C
FCGM-XP01-050 532nm 0,050W 10 to 40°C
FCGM-XP01-050L 532nm 0,050W 10 to 40°C
FCGM-XP01-100 532nm 0,100W 10 to 40°C
FCGM-XP01-100L 532nm 0,100W 10 to 40°C
FOLM-633-40-LM 633nm 0,040W 10 to 45°C
FOLM-633-70-LM 633nm 0,070W 10 to 45°C
FOLM-633-70-RO 633nm 0,070W 10 to 40°C
ML-AR02-635-01 634nm 0,001W 0 to 40°C Ø6.2mm
ML-AR03-635-01 634nm 0,001W 0 to 40°C Ø8mm
ML-AR04-635-01 634nm 0,001W -5 to 50°C Ø10.5mm
ML-AR05-635-01 634nm 0,001W -5 to 50°C Ø10.5mm
ML-AR02-635-03 634nm 0,003W 0 to 40°C Ø6.2mm
ML-AR03-635-03 634nm 0,003W 0 to 40°C Ø8mm
ML-AR04-635-03 634nm 0,003W -5 to 50°C Ø10.5mm
ML-AR05-635-03 634nm 0,003W -5 to 50°C Ø10.5mm
FAL-635-X.X-GS 635nm 0,005W 0.4 to 5mW
FPYL-635-XXT-LC 635nm 0,030W 1 to 30mW 20 to 30°C
FPYL-637-XXT-LC 637nm 0,080W 1 to 80mW 20 to 30°C
FPYL-637-XXXT-XS 637nm 0,100W 1 to 100mW 10 to 35°C
FOLM-640-15-FC 638nm 0,015W 10 to 45°C
FOLM-638-30-LM 638nm 0,030W 10 to 45°C
FOLM-638-30-RO 638nm 0,030W 10 to 40°C
FOLM-638-120-RO 638nm 0,120W 10 to 40°C
FPYL-640-XXT-LC 640nm 0,030W 1 to 30mW 20 to 30°C
FPYL-642-XXT-LC 642nm 0,030W 1 to 30mW 20 to 30°C
FPYL-642-XXXT-XS 642nm 0,100W 1 to 100mW 10 to 35°C
FAL-650-X.X-GS 650nm 0,005W 0.4 to 5mW
FPYL-650-XXT-XS 650nm 0,080W 1 to 80mW 10 to 35°C
ML-AR01-650-01 655nm 0,001W 0 to 40°C Ø4mm
ML-AR02-650-01 655nm 0,001W 0 to 40°C Ø6.2mm
ML-AR03-650-01 655nm 0,001W 0 to 40°C Ø8mm
ML-AR04-650-01 655nm 0,001W -5 to 50°C Ø10.5mm
ML-AR05-650-01 655nm 0,001W -5 to 50°C Ø10.5mm
ML-AR06-650-01 655nm 0,001W 0 to 40°C Ø6.5mm
ML-AR07-650-01 655nm 0,001W 0 to 40°C Ø3.3mm
ML-AR17-650-01 655nm 0,001W 0 to 40°C Ø3.3mm
ML-AR02-650-03 655nm 0,003W 0 to 40°C Ø6.2mm
ML-AR03-650-03 655nm 0,003W 0 to 40°C Ø8mm
ML-AR04-650-03 655nm 0,003W -5 to 50°C Ø10.5mm
ML-AR05-650-03 655nm 0,003W -5 to 50°C Ø10.5mm
ML-AR06-650-03 655nm 0,003W 0 to 40°C Ø6.5mm
ML-AR12-650-05 655nm 0,005W -5 to 40°C Ø10.5mm
FPYL-655-XXT-XS 655nm 0,080W 1 to 80mW 10 to 35°C
FOLM-658-12-FC 658nm 0,012W 10 to 45°C
FPYL-660-XXT-XS 660nm 0,080W 1 to 80mW 10 to 35°C
FOLM-685-40-RO 685nm 0,040W 10 to 40°C
FOLM-690-40-LM 690nm 0,040W 10 to 45°C
FPYL-705-XXT-LC 705nm 0,010W 1 to 10mW 20 to 30°C
FPYL-705-XXT 705nm 0,025W 1 to 25mW 10 to 35°C
FAL-780-X.X-GS 780nm 0,005W 0.4 to 5mW
ML-AR01-780-01 785nm 0,001W 0 to 40°C Ø4mm
ML-AR06-780-01 785nm 0,001W 0 to 40°C Ø6.5mm
ML-AR07-780-01 785nm 0,001W 0 to 40°C Ø3.3mm
ML-AR17-780-01 785nm 0,001W 0 to 40°C Ø3.3mm
ML-AR01-780-03 785nm 0,003W 0 to 40°C Ø4mm
ML-AR06-780-03 785nm 0,003W 0 to 40°C Ø6.5mm
ML-AR07-780-03 785nm 0,003W 0 to 40°C Ø3.3mm
ML-AR17-780-03 785nm 0,003W 0 to 40°C Ø3.3mm
FPYL-785-XXT-XS 785nm 0,080W 1 to 80mW 10 to 35°C
FOLM-785-500-FC 785nm 0,500W 10 to 45°C
FPYL-808-XXT-XS 808nm 0,080W 1 to 80mW 10 to 35°C
FOLM-830-500-FC 830nm 0,500W 10 to 45°C
ML-AR01-850-01 845nm 0,001W 0 to 40°C Ø4mm
ML-AR06-850-01 845nm 0,001W 0 to 40°C Ø6.5mm
ML-AR07-850-01 845nm 0,001W 0 to 40°C Ø3.3mm
ML-AR17-850-01 845nm 0,001W 0 to 40°C Ø3.3mm
ML-AR01-850-03 845nm 0,003W 0 to 40°C Ø4mm
ML-AR06-850-03 845nm 0,003W 0 to 40°C Ø6.5mm
ML-AR07-850-03 845nm 0,003W 0 to 40°C Ø3.3mm
ML-AR17-850-03 845nm 0,003W 0 to 40°C Ø3.3mm
FAL-850-X.X-GS 850nm 0,005W 0.4 to 5mW
FPYL-915-XXXT-XS 915nm 0,100W 1 to 100mW 10 to 35°C
FPYL-940-XXXT-XS 940nm 0,100W 1 to 100mW 10 to 35°C
FPYL-1310-XXT-DFB 1.310nm 0,010W 1 to 10mW 22 to 28°C
FPYL-1450-XXXXT 1.450nm 1,000W 1 to 1000mW 10 to 35°C
FPYL-1550-XXT-NL 1.550nm 0,010W 1 to 10mW 15 to 35°C
FPYL-1550-XXT-DFB 1.550nm 0,030W 1 to 30mW 22 to 28°C
FLIR-100-A IR 800 to 860nm -40 to 60°C
HAML
HAML-E
HAML-F
HNML 532 to 1060nm -10 to 50°C
HSML
HSML-mini 635 to 1060nm 1 to 10mW -10 to 50°C
ML126FC
ML150FC
ML1xxFC
MLG
